Cable Recycling Granulator Machine

Your Professional Cable Recycling Granulator Machine Supplier！

Xi'an RJ Mechanical Equipment Co., Ltd. was established in 2010 and is located in the High-Tech Industria. The factory specializes in manufacturing industrial machinery including cable granulator machines,wire stripping machines, radiator recycling machines,motor stator recycling machines, balers,shredders.and alligator cutter machines.

First 12 3 Last 1/3

Product Specification

We offers the following product introduce specifications：

Name	E-S35
Power	75.36KW
Process capacity	600~800kg/h
Weight	8000KG
Wire range	0.1~35mm
Measurement	6X11X2.25m

Advantages of Cable Recycling Granulator Machine

01/

Efficient Scrap Processing
A Copper Cable Granulator efficiently processes Scrap Wires, separating Copper from the Insulation. This process not only Reduces Waste but also allows for the extraction of valuable metals that can be reused or sold.

02/

Cost Savings
By Recycling Scrap Cables with a Granulator Machine, businesses can reduce Raw Material Costs. The recovered Copper and other Metals can be reused in Manufacturing Processes, lowering the need for purchasing New Materials.

03/

Environmental Sustainability
Cable Granulators contribute significantly to Environmental Sustainability by reducing Landfill Waste and minimizing the need for Mining Raw Materials. Recycling Metals like Copper conserves Natural Resources and reduces Carbon Emissions associated with Metal Production.

04/

Increased Profitability
Investing in a Copper Cable Granulator Machine can lead to increased Profitability through the sale of Recovered Metals. The machine helps extract High-purity Copper, which commands a good market price, thereby enhancing your Revenue Streams.

05/

Versatility and Scalability
Modern Cable Granulator Machines are versatile and can handle various Types and Sizes of Cables, adapting to your business's needs as it grows. They offer Scalability, allowing you to process Larger Volumes of Scrap over Time.

06/

Improved Operational Efficiency
Using a Cable Granulator Machine streamlines your Recycling Process, reducing Manual Labor and Operational Costs associated with Handling and Disposing of Scrap Cables Manually.

Common types

There are three types of cable granulators, the wet, the dry, and static type.

The wet type granulator is a traditional type of cable granulator which mainly uses a gravity shaker, using water to separate copper from the plastic.

The dry type granulator uses air classifiers or an air shaker. The static type high voltage electrostatic separation to detach the copper and plastic from each other.

Application of Cable Recycling Granulator Machine

Scrap Metal Recycling Stations

The primary use is processing various cable types—including thick armored cables, fine telephone wires, and data cables—to separate metals from plastics.

Wire and Cable Manufacturers

Internal recycling of production scrap and defective cables to recover materials, reducing waste and raw material costs.

Electronic Waste Treatment (E-Waste)

Handling materials from household appliances, computer wires, and communication cables, which are often rich in, or mixed with, plastic insulation.

Vehicle Demolition

Processing waste cables from end-of-life automobiles and motorcycles.

Specialized Material Recovery

Capable of handling complex, oily, or sticky cables, such as submarine cables.

Structure of Cable Recycling Granulator Machine

The system adopts two-stage dust removal, which can separate most of the dust through a cyclone, effectively protecting the service life of the pulse dust bag;

The structure of rotor and blade is more suitable for cutting wires and cables;

The gap between the movable blade and the fixed blade can be locked to effectively control the loss of copper powder caused by the expansion of the gap;

Using 7 groups of 14 movable blades to effectively increase the output of secondary crushing;

The opening and closing of the upper chamber cover and the screen bracket of the crusher are all hydraulically controlled and automatically controlled;

Material Compatibility

Certifications

Package & Delivery

Package: Standard export package or Custom

Delivery: By air express, by sea

productcate-1-1

FAQ

Q: How much power does the cable granulator machine consume?

A: Our copper granulator has been continuously updated. We control the power consumption less than about 70% of the machine power, helping you save electricity costs as much as possible.

Q: How do I install the copper granulator machine?

A: For the small copper granulator, it's integrated type, you only need to connect to the power and it will normal to work.
For the big model, only need to assemble ,we will send you the installation manual, it is very easy to install.
We also supply overseas installation to our customer, but customer need to burden all technician costs.

Q: Does the cable granulator machine have CE file report?

A: Our machines are all CE certified, and we will also put the CE mark on the machine. When your machine is shipped, we will send you the CE certification and all the documents.

Q: Does the copper granulator have to be paid in full at one time?

A: When you decide to order our machine, you can pay a 30% advance payment first. After the machine is finished, we will send you a test video to ensure that the machine is operating normally. After confirmation, we will arrange shipment after you pay the remaining 70% of the balance.

Q: How do I import a cable granulator machine?

A: We will ship the machine to the port closest to you. After the machine arrives, the freight forwarder will notify you. After your agent completes the freight clearance formalities, you can pick up the machine at the port.

Q: Why the copper outlet have little plastic? What should I do?

A: The suction fan is too windy, you only need to lower the wind speed of the suction fan.

Q: What are the worn parts of cable granulator machine?

A: The wear parts are crusher blades, crusher screen, vibrating table screen, air separator screen. We will send 3 crush sieves with machine for free and you can purchase several parts as spare use.

Q: How can I choose a suitable copper cable granulator machine among so many types?

A: According to the wire diameter and capacity requirements, you'd better send us the picture about your scrap cable wire, we will recommend the suitable for you.

Q: Can I only buy one part of the cable granulator machine?

A: I feel so sorry, generally we do not sell separately, because we have no idea about your other parts so can't assure the machine working effect. For better efficiency, we suggest you buy 1 entire set.

Q: What's your best delivery time?

A: Within 15-30 days.

Q: Is OEM open to clients?

A: Yes, we can provide both OEM and ODM service.

Q: What is the payment of sample?

A: T/T and Alipay both acceptable.

Q: What is your packing?

A: Yes, our packaging is genuine original packaging. Of course, we can also provide neutral packaging or according to your requirements

Q: Have you tested all your goods before shipment?

A: Yes, we will conduct 100% test before delivery, and we will send detailed photos of parts for your approval .
