Xi'an RJ Mechanical Equipment Co., Ltd. is one of the leading manufacturers and suppliers of Large Industrial Copper Wire Granulator in China. Welcome to buy CE approved Large Industrial Copper Wire Granulator made in China here from our factory. Quality products and reasonable price are available.
Products Description
The E-S35 Copper Wire/Cable Shredder is a professional dry-type shredding machine featuring a well-engineered design that integrates automatic shredding, feeding, dust removal, and separation processes into a single unit, enabling multiple processing steps to be completed in a single feed without the need for additional auxiliary equipment. Designed specifically to process various types of scrap cables unsuitable for wire stripping machines, this equipment efficiently handles wiring harnesses from automobiles, motorcycles, and electric vehicles, as well as cables from household appliances, telecommunications equipment, and computers. Through dry separation and an automatic screening system, it achieves precise separation of plastic and copper. The separated products are ready for direct sale, making this a highly efficient, specialized solution for the cable resource recycling industry.
Machine Parameters
| Name | E-S35 |
| Power | 75.36KW |
| Process capacity | 600~800kg/h |
| Weight | 8000KG |
| Wire range | 0.1~35mm |
| Measurement | 6X11X2.25m |
Product Advantages
1. Highly Integrated, Saving Time and Labor
The system integrates the entire process-feeding, crushing, dust removal, and separation-into a single unit. A single batch of feedstock completes multiple processing steps, eliminating the need for frequent manual intervention. Operational efficiency far exceeds that of traditional multi-stage equipment, significantly reducing labor and time costs.
2. Dry-Process Technology: Environmentally Friendly and Efficient
Utilizing dry crushing and separation technology, this system produces no wastewater pollution. Combined with an advanced dust collection system, it ensures controllable dust levels and high separation precision. Copper and plastic are thoroughly separated, and the resulting products are ready for direct sale, thereby enhancing the value of the recycled materials.
3. Highly Targeted and Exceptionally Adaptable
Specifically designed for scrap cables and complex wire harnesses that wire strippers cannot process, it requires no pre-sorting or stripping-simply feed and crush. This efficiently addresses the pain points associated with traditional equipment.
4. Superior Construction and Stable Operation
The machine features a compact design with precision-engineered, durable core components that are resistant to wear and impact. It supports long-term, high-intensity continuous operation with low failure rates, controllable maintenance costs, and a long service life.
Applications
1. Cable Recycling Facilities: Processes various types of scrap cables and wiring harnesses to separate and recycle copper and plastic, directly producing marketable products and increasing recycling revenue.
2. Automotive/Electric Vehicle Dismantling: Processes scrap wiring harnesses generated from the dismantling of automobiles, motorcycles, and electric vehicles, efficiently recovering copper wire resources and facilitating the resource utilization of components.
3. Home Appliance Dismantling Companies: Processes cables from the dismantling of home appliances such as televisions, washing machines, refrigerators, and air conditioners; achieves separation of copper and plastic; and increases the added value of appliance recycling.
4. Telecommunications/Electronic Waste Processing: Processes waste cables from telecommunications equipment and computers; precisely separates copper and plastic; enables resource recycling; and meets environmental protection requirements.
Important Notes
1. Before feeding copper wires and cables into the shredder, first sort out other materials (such as iron) to prevent damage to the shredder blades. When feeding cables into the machine, pay close attention to the shredding speed of the shredder.
2.During production, pay attention to whether the machine is producing abnormal noises. If unusual sounds are detected, immediately shut down the machine and open the shredder housing for inspection.
3.During production, if excessive plastic-coated copper particles or particles that are too small are detected, replace the screen mesh or adjust the gap between the fixed blade and the rotating blade.
4.If the machine tends to overheat, stop the machine and check whether there is friction in the transmission components.
Machine Assembly and Commissioning
Upon arrival of the equipment, please arrange it appropriately under the manufacturer's guidance, taking into account the product layout and actual site conditions, to ensure smooth production operations.
After completing the overall system layout, connect the power supply to the designated interface and initiate the test run. The operational steps are as follows:
1.Verify that the emergency stop function of the main power switch is operational. After the indicator light illuminates, test whether the emergency stop device and main power switch are functioning correctly.
2.Do not perform test runs on a single machine.
3.Manually start and stop each component in sequence. Verify that all components start and stop normally, check for abnormal noises during operation, and confirm the rotation direction is correct. If any issues are detected, promptly contact the manufacturer for resolution.
4.The entire machine operates through an interlocking mechanism.
5.After confirming that all components operate normally in manual mode, start the entire machine using the buttons on the control panel. Observe whether the machine starts up correctly, whether all components operate in coordination, if there are any abnormal noises during operation, and whether the running direction is correct.
WHAT KIND OF CABLES CAN BE PROCESS
The final separation results show
Operational Procedure
Testing and Packaging
Certification
Our factory
Xi'an RJ Mechanical Equipment Co. Ltd. was established in 2010 and is located in the High-Tech Industria. The company occupies an area of 5,000 square meters,employs 100 staff members and possesses an annual production capacity valued at $30 million USD. The factory specializes in manufacturing industrial machinery including cable granulator machines wire stripping machines radiator recycling machines motor stator recycling machines balers shredders.and alligator cutter machines.
FAQ
Q: How can i trust your company?
A: a. With professional design and sales team, we can serve you the perfect solution with lowest cost. b. Assessed by third party, national patents for all equipment, also CE, ISO, TUV. c. Agents in RU, US, UKR, MYS, PH; Users around the world. d. Welcome to inspect anytime.
Q: How about the test running & installation?
A: Before delivery, we finish the test over 3 days. If you take integral design, no need to installation at all. If parted design, we can send our technicians to your place if necessary.
Q: Any warranty?
A: Under the proper usage, one year for whole machine except the wear parts.
